Master-PUR HX Food A
Application
- Suction & transport hose for the food industry for solids and liquids
- Phamaceutical industry
- Chemicals
Properties
- plasticizer and holgen-free
- extremely abrasion resistant via specific reinforcements underneath the spiral
- good flexibility
- good chemical resistance
- generally good UV and ozone resistance
- gas-tight
- increased pressure and vacuum resistance
- high tensile strength
- mostly smooth inner lining
- optimum flow characteristics
- EU guidelines 2002/72/EU and most recent amending directives
- microbe and hydrolysis proof
- acc. to TRBS 2153 (Zone 20) for non-flammble dust/bulk solids for conducting electrostatic charges
- odourless/tasteless
- surface resistance ≤ 109 Ohm
- Materials comply with the following food regulations:
- FDA 21 CFR §177.2600
- FDA 21 CFR §178.2010
Chemical Resistance
Recommended Connecting Elements:
Index Number:
4.5.3
Product Description
PU suction & Transport Hose, heavy-weight, food-grade (FDA), antistatic < 109Ohm
Material
- spiral: anti-rust spring steel wire (material no. 1.4310)
- wall: pure polyether polyurethane, food-grade (FDA), with non-migratory permanent antistatic agent
- wall thickness between spirals approx. 1.7 - 2.1 mm, depending on DN
Temperature Range
- -40°C up to +90°C
- intermittent to +125°C
Construction
- moulded twist and dislocation-proof VA spring steel spiral
- wall thickness between spirals approx. 1.7 - 2.1 mm depending on DN
- Wear-zones with extra reinforcement
- wall: pure polyether polyurethane, food-grade (FDA), with non-migratory permanent antistatic agent
